Can I mix R-20 and R-60 in one house?

Yes. Mixing R-values across assemblies is common. Prioritize the building elements with the largest heat-loss area and worst exposure first—typically the attic and any uninsulated foundations. For example, a practical path is to bring walls to an R-20 cavity level and increase attic insulation toward R-60, or combine R-20 cavities with exterior continuous insulation on walls to offset thermal bridging. Make sure transitions between assemblies are detailed to avoid thermal or moisture traps where different materials meet.

Will R-60 in the attic make wall insulation less important?

No. Attics and walls control different heat paths. Adding R-60 in the attic reduces overall heating load, but poorly insulated walls can still create cold spots, uncomfortable interior surfaces, and moisture risk. A balanced upgrade strategy—addressing attic, walls, and air sealing—delivers the best comfort and energy results.

How thick is R-60 and will it fit in my attic?

Thickness depends on material: loose-fill cellulose or fiberglass may require roughly 16–24+ inches to reach R-60, while high-performance spray foam needs far less thickness (closed-cell has higher R/inch). Many older attics lack the depth for R-60 without adding framing or using a spray-foam hybrid. Inspect attic joist depth and ventilation before planning; raised-heel trusses are a common new-build solution to allow full-depth insulation at eaves.

Is spray foam the only way to get to R-60?

No. You can reach R-60 with layered loose-fill (cellulose or fiberglass), batts stacked in layers, or by combining a thin spray-foam air barrier with a thick loose-fill top-up. Spray foam reduces thickness but increases cost. For DIYers, dense-pack cellulose or layered loose-fill is a common, cost-effective route to R-60 attic performance.

Do building codes require R-60 anywhere?

Code requirements vary by jurisdiction and climate zone. The International Energy Conservation Code (IECC) and local amendments set minimums by climate; some cold-zone codes expect higher attic R-values. Always check local code and inspector guidance before major work. For national-level guidance on cost-effective R targets by climate, consult Energy Star and DOE resources such as the Energy star recommended r-values and DOE insulation guidance at energy.gov.

R-20 vs R-60 Insulation: Which Do You Need?

R-Value Comparisons

Compare R-20 and R-60 insulation, costs, performance, installation methods, and which option fits your climate and DIY budget.

By Graham Mann | Published: 6/28/2026

R-20 vs R-60 Insulation: Which Do You Need? Choosing between R-20 and R-60 insulation is a common decision for budget-conscious DIY builders who want to balance upfront cost, space, and long-term energy bills. This article compares the two targets, explains how R-value affects heat loss, shows common assemblies and installation methods, and gives scenario-based recommendations so you can pick the right approach for your climate, budget, and build type. The primary search term "r20 vs r60 insulation" appears throughout to help you find the most relevant guidance. TL;DR: - Upgrading an attic from R-20 to R-60 cuts steady-state conductive heat flow by about 67% (heat flow scales with 1/R). - For mild climates or tight budgets, R-20 cavity insulation plus air sealing and some continuous exterior insulation often gives the best cost-to-comfort ratio. - For cold-climate new builds or deep retrofits, aim for R-60 in the attic (or equivalent continuous strategies) plus airtightness for long-te...
